| 型号 | 扭矩范围 Nm | 最高转速 rpm | 握把直径 mm | 产品尺寸 mm | 重量 g | 批头快换 | 工具控制器 | 电压功率 |
|---|---|---|---|---|---|---|---|---|
| PTC-DSH-1000M-33-HMP-000-B | 0.02~0.1 | 3000 | 33 | 247.2 | 345.6 | HM4 | OPT-SCS-001-CD1-B3-500W OPT-SCS-007-CD1-B3-500W |
500W 24V |
| PTC-DSH-2400M-33-HMP-000-B | 0.05~0.24 | 3000 | 33 | 247.2 | 427 | OPT-SCS-001-CD1-B1-500W OPT-SCS-007-CD1-B1-500W |
||
| PTC-DSH-0009N-33-H1P-000-B | 0.18~0.9 | 3000 | 33 | 268.8 | 536 | HEX1/4" | ||
| PTC-DSH-0020N-33-H1P-000-B | 0.4~2 | 1500 | 33 | 291.5 | 580 | OPT-SCS-001-CD1-B2-500W OPT-SCS-007-CD1-B2-500W |
||
| PTC-DSH-0020N-40-H1P-000-B | 0.4~2 | 3000 | 40 | 273.7 | 885.1 | |||
| PTC-DSH-0040N-40-H1P-000-B | 0.8~4 | 1500 | 40 | 285.7 | 963.2 | |||
| PTC-DSH-0080N-40-H1P-000-B | 2~8 | 960 | 40 | 290.7 | 1000.1 | |||
| PTC-DSH-0120N-40-H1P-000-B | 4~12 | 700 | 40 | 290.7 | 996.1 | |||
| PTC-DSH-0200N-40-S2P-000-B | 7~20 | 300 | 40 | 302.2 | 1098.4 | S 3/8" |
